HIGH PRECISION WATER BATH CIRCULATORY
“MATRIX” Bacteriological incubators are high-quality incubators whose forced convection system guarantees good mixing, strong dispersion, and ensures superior temperature uniformity inside the chamber .
Features
It’s a suitable tool for a variety of applications and industries including Biotechnology, Clinical, Environmental, Medical, Petroleum, Pharmaceuticals.
It is created to deliver the highest level of performances, control and flexibility for most demanding industrial and general-purpose applications.
TECHNICAL FEATURES AND ORDERING INFORMATION
| Model | MET-152 |
|---|---|
| Inner Size | 430X240x265 |
| capacity | 27 ltrs |
| Temperature Range | Ambient to 100°C |
| Temperature Sensitivity | +/0.5°C |
| Controller | Microprocessor based PID Digital Temperature Indicator-cum- Controller/ HMI touch Screen Controller |
| Temp. Sensor | RTD (PT-100) |
| Heating Load | 1.5KW (1.0 KW +0.5KW) |
| Lack Manual & lack Up Height | 100mm |
| Inner Body | SS 304 |
| Outer Body | M.s with Powder Coating Or SS 304 AS ordered |
| Alarm | ON/OFF Cycle |
| Auto Control | With respect to temp. & time within Built timer & Buzzer alarm . |
| Temperature Display | LED Display For set value (SV) & process Value (PV) |
| Stirrer Device | Motor (1/20HP) |
| Diffuser Self | Heater protective perforated cover made of stainless steel. |
| Regulator | Solid steel electronic relav with protective heat sink. |
CONSTRUCTIONAL FEATURES
- Maintenance of maximum temperature due to Microprocessor Based PID Digital Temperature Indicator-cum-Controller.
- Controlling of difference between real temperature and indicated temperature with user’s Self-compensation function.
- Stainless Steel Bath to deliver high durability & thermal efficiency .
- Flat Stainless Steel Lid to stop evaporation and ensure constant temperature .
- Use of industrial grade energy efficient heaters to cut down on power bill.
- Double walled construction.
- Use of a special grade mineral wool in space between the walls to avoid thermal losses.
- Equipped with drain plug to ensure user convenience.
- Able to manage and control temperature within an accuracy of +0.3oC.
- The unit is delivered with stirring arrangement.
- The stirring arrangement comes fitted with a FHP motor containing SS stirring shaft to enable continuous stirring and helping maintain a uniform temperature throughout.
- Speed regulator is present in the front panel to control the stirrer.
- Stainless Steel (SS-304 grade)-made Inner bath chamber and lid.
- Outer chamber constructed using Mild Steel sheet duly powder coated.
- AC supply to work on 220/230V.
